I will develop high speed iot pcb with esp32 c6, cellular modern and rf layout

High Speed IoT PCB Design with ESP32-C6, Cellular Modem and RF Layout

Wireless IoT hardware combines several sensitive design areas, including high speed digital interfaces, RF transmission lines, cellular communication and power management.

I develop high speed IoT PCBs using ESP32-C6, cellular modems and RF layout techniques for connected devices, tracking systems, industrial sensors and smart embedded products. I focus on clean routing, controlled return paths, effective grounding and practical manufacturing requirements.

What I offer:

• ESP32-C6 IoT PCB development
• Cellular modem integration
• WiFi and LTE RF layout
• High speed differential pair routing
• USB, UART, SPI and I²C interfaces
• RF keep outs and ground via stitching
• Antenna and matching network layout
• Power regulation and battery management
• 2 layer and 4 layer PCB design
• KiCad and production ready files

What you will get:

• Organized high speed PCB layout
• RF aware component placement
• Gerber and drill files
• BOM and pick and place files
• DRC and layout review
• Manufacturing documentation

Contact me with your schematic, modem details and board specifications to get started.
