I will design an ips display and usb c charging pcb for your handheld console

Modern screen, USB-C charging, and a board shaped to your shell not a

generic one you have to file down.

I design IPS display adapters and USB-C power boards for handheld console

mods, including Game Boy revisions. You send me your revision and panel;

I send back a fab-ready design package for JLCPCB or PCBWay.

WHAT YOU GET

- Schematic PDF covering charging, protection and level shifting

- Gerbers, drill files, BOM and pick-and-place (CPL)

- Board outline checked against your shell, with cutout dimensions

- Assembly notes: solder points, wire runs, install order

HOW IT WORKS

1. Message me with your revision and panel part number before ordering

2. I confirm feasibility and quote if it sits outside a package

3. I design, then we do a review round before files are finalised

4. Delivery with assembly notes

WHAT I NEED FROM YOU

- Exact board revision (e.g. DMG-CPU-06) and shell you're using

- Part number of the panel and battery you've bought or plan to buy

- Photos of both sides of your board

NOT INCLUDED

Fabrication, assembly, components and shipping. You order the boards

yourself I'll point you to the cheapest route for your quantity.

Message me before ordering.
