I will design advanced multi layer pcbs and industrial hardware layouts
Industrial IoT Embedded Systems Engineer
Informazioni su questo servizio
Transform your circuit schematics into high-performance, manufacturing-ready printed circuit boards. I specialize in complex, multi-layer industrial PCB designs optimized for signal integrity, thermal dissipation, and rigorous EMI/EMC compliance.
What I Do:
High-Speed Layouts: Multi-layer routing (4 to 12+ layers) with precise impedance control and differential pair routing.
Industrial Ruggedness: Power distribution network (PDN) optimization, thermal vias, and isolation for high-voltage environments.
DFM/DFA Compliance: Layouts designed strictly according to IPC standards for seamless automated assembly.
Component Selection: Sourcing reliable, industrial-grade components to minimize supply chain risks.
Why Choose This Service?
Unlimited Revisions: I refine the layout until your manufacturer approves it without technical flags.
Production-Ready Deliverables: You receive full Gerber X2 files, BOM with supplier part numbers, pick-and-place files, and 3D STEP models.
Lets get your board ready for production. Message me today with your schematic or project details to get a custom quote before placing an order!
Specializzazione:
Progettazione circuito
•
Layout
•
Analisi
Formato di file:
Gerber
•
STEP
•
SCH
•
•
Pcbdoc
Software:
Allegro
•
Altium Designer
•
Eagle CAD
•
KiCad
Altri servizi della categoria Ingegneria elettronica offerti da me
FAQ
Do you provide the source design files?
Yes, native Altium or KiCad source files are included in the Standard and Premium packages, or available via custom add-ons.
What if my board fails manufacturer checks?
Every layout includes unlimited revisions. If your fabricator finds any issues, I will fix the files immediately at no extra cost.
