I will create railing shop and fabrication drawings
NAGALINGAM M
Informazioni su questo servizio
Hi, I have a total of 18+ years of drafting experience, including the last 8 years working remotely with Livers Bronze LLC, Kansas City, USA.
During the last 8 years, I have completed 800+ commercial & ressidential railing projects, including approval drawings and final fabrication drawings for more than 15 types of railing systems
I have strong experience in:
Glass railing systems
Cable railing systems
Panel railing systems
Stair and balcony railings
Shop drawings
Fabrication drawings
Installation drawings
Glass manufacturing drawings
Post and stub manufacturing drawings
Cable manufacturing drawings
Trim manufacturing drawings
Panel manufacturing drawings
1-line post manufacturing drawings
I also prepare drawings with proper AutoCAD standards including:
Organized layers
Proper text styles
Dimension styles
Dynamic blocks and standard blocks
Clear annotations and callouts
Fabrication and installation detail
I specialize in preparing accurate, detailed, and fabrication-ready drawings based on US standards for commercial and residential projects. I can provide plan views, elevations, sections, layout sheets, and production-ready mfg. drawings for fabrication and installation.
