Are you looking for an experienced mechanical and structural designer to handle your 3D modeling, fabrication drawings, and realistic renderings? You are in the right place!

I specialize in high-quality mechanical 3D modeling and detailed technical drafting using AutoCAD, SketchUp, and Revit. With professional engineering experience in industrial design, I deliver accurate, production-ready solutions tailored for manufacturing, workshops, and large-scale plant systems.

️ My Specialized Services Include:

  • WTP & STP Plant Modeling: Complete 3D modeling and piping layouts for Water Treatment Plants (WTP) and Sewage Treatment Plants (STP).
  • Industrial 3D Modeling: High-detail silos, pressure vessels, storage tanks, and chemical dosing tanks.
  • Component Design & Detailing: Precision models of industrial submersible pumps, valves, strainers, fittings, flanges, and penstock gates.
  • Fabrication & Workshop Drawings: Production-ready 2D AutoCAD mechanical drawings with accurate structural detailing.
  • Cutting Plans & Assembly Layouts: Optimized cutting plans to streamline workshop fabrication and minimize material waste.
  • BOQ & Material Takeoffs: Accurate preparation of Bill of Quantities (BOQ) and
